CAMERA |
Image Sensor |
1/1.79” Progressive Scan CMOS |
Shutter Speed |
1/3 to 1/10000 s |
Slow Shutter |
Yes |
Minimum Illumination |
0.0005 Lux; 0 Lux with White Light |
Day/Night Mechanism |
N/A |
Day/Night Switch |
Unified/Scheduled/Auto |
LENS |
Type |
Fixed Focal Lens |
Focal Length |
4 mm |
Aperture |
F1.0±5% |
FOV |
4mm: |
Horizontal FOV: 104°, Vertical FOV: 55°, Diagonal FOV: 127° |
Lens Mount |
M16*P 0.5 |
DORI Distance |
4 mm: |
Detect: 63 m (207 ft) |
Observe: 26 m (86 ft) |
Recognize: 13m (41 ft) |
Identify: 6 m (21 ft) |
PTZ |
Pan/tilt Range |
Pan: 0° to 348°, Tilt: 0° to 105° |
Pan/tilt Speed |
Pan Speed: |
Configurable from 8° to 44°/s; Preset Speed: 44°/s |
|
Tilt Speed: |
Configurable from 8° to 44°/s, Preset Speed: 44°/s |
Manual Control Speed |
Configurable from 8° to 35°/s |
Presets |
300 |
Patrol Scan |
8 patrols, up to 8 presets for each patrol |
Power-off Memory |
Yes; |
Auto restore to previous PTZ and lens status after power failure |
Park Action |
Yes; |
Preset; Patrol Scan |
3D Positioning |
Yes |
Angle Adjustment (Manual) |
Range |
Pan: 0° to 348° |
Tilt: 0° to 105° |
ILLUMINATOR |
IR LED |
N/A |
White LED |
Quantity: 2 |
Range: 30m |
Illuminator On/Off Control |
Auto/Scheduled/Always on/Always off |
VIDEO |
Max. Resolution |
2688 x 1520 |
Main Stream |
Frame Rate: |
50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps |
60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps |
|
Resolution: |
2688x1520, 2560x1440, 2304x1296, 2048x1280, 1920x1080, 1280x720 |
Sub-Stream |
Frame Rate: |
50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps |
60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps |
|
Resolution: |
704x576, 640x480, 352x288, 320x240 |
Bit Rate Control |
CBR, VBR |
Video Compression |
Main Stream: H.265+/H.265/H.264+/H.264 |
Sub-Stream: H.265/H.264 |
H.264 Type |
Main Profile/High Profile |
H.264+ |
Main Stream Supported |
H.265 Type |
Main Profile |
H.265+ |
Main Stream Supported |
Video Bit Rate |
Main Stream: 256 Kbps to 6 Mbps |
Sub-Stream: 64 Kbps to 512 Kbps |
Image |
Image Settings |
Mirror, Brightness, Contrast, Saturation, Sharpness, Exposure, WDR, |
White Balance, Prevent Overexposure to Infrared Light, HLC Adjustable by Client Software |
Image Enhancement |
BLC/3D DNR/HLC |
Wide Dynamic Range |
120dB |
SNR |
? 52 dB |
Image Parameters Switch |
Yes |
Privacy Mask |
Up to 4 Masks |
ROI |
1 Region |
OSD Setting |
Yes |
AUDIO |
Audio Communication |
Two-Way Audio |
Audio Input |
Yes |
Audio Output |
Yes |
Audio Compression |
Yes |
Audio Sampling Rate |
8KHz |
Environment Noise Filtering |
Yes |
Audio Bit Rate |
64 Kbps(G.711 alaw) |
NETWORK |
Protocol |
TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS |
ONVIF |
Yes |
API |
ONVIF |
Simultaneous Live View |
3 Main Streams & 3 Sub-Streams |
Client |
VIGI App, VIGI Security Manager, Web UI |
Web Browser |
Google Chrome® 57 and above |
Firefox® 52 and above |
Safari® 11 and above |
Microsoft® Edge 91 and above |
Cloud |
Yes |
Security |
Password Protection, HTTPS Encryption, IP Address Filter, Digest Authentication |
ALARM AND EVENT MANAGEMENT |
Smart Event |
Human & Vehicle Classification, Intrusion Detection, Line-Crossing Detection, People Detection, Vehicle Detection, Region Entering Detection, Region Exiting Detection, Abandoned Object Detection, Object Removal Detection, Loitering Detection, Scene Change Detection, Smart Frame |
Basic Event |
Motion Detection, Video Tampering Detection, Exception ( Illegal Login) |
Alarm Linkage |
Memory Card Video Recording, Message Push, Audible Warning, White Light Flashing |
Linkage Method |
N/A |
Output Notification |
Message Push |
Deep Learning Function |
People & Vehicle Analytics |
Search and filter to people or vehicle of interest based on many different attributes, making post-event search faster and easier. |
INTERFACES |
Network Interface |
1 RJ45 10/100M Self-Adaptive Ethernet Port, PoE |
Alarm |
N/A |
Reset Button |
Yes |
Power |
DC Power Port |
On-board Storage |
Built-In Memory Card Slot, Support MicroSD Card, Up to 512 GB |
Built-in Microphone |
Yes; Records Anything Going on within a 15-ft Radius of the Camera |
Built-in Speaker |
Yes |
Audio |
N/A |
GENERAL |
